The XFP 10G EPON OLT optical module provides high bandwidth access capability, supporting the high-speed data transmission needs of large-scale users. It can be applied to scenarios such as telecommunications operators and broadband access providers to build high-performance 10G EPON fiber optic access networks, meeting the needs of users for various services such as high-speed internet access, video streaming, and cloud computing.
Single fiber bi-directional data links TX 10.3125Gbps, Burst Mode RX 10.3125Gbps application
Single fiber bi-directional data links TX 1.25Gbps, Burst Mode RX 1.25Gbps application
0 to 70°C operating case temperature
3.3V, 5V power supply
XFP package with SC Receptacle connector
Hot-pluggable capability
High power 1577 nmEML LD and High power 1490nm DFB LD
High sensitivity 1270nm and 1310nm APD
Support 20km transmission distance with SMF
LOS indication
Low EMI and excellent ESD protection
Digital diagnostic monitor interface
RoHS2.0 compliance
APPLICATIONS：
Symmetric 10GEPON OLT
GEPONPX 20+ OLT
STANDARDS：
Complies with INF-8077i
Complies with IEEE 802.3av
Complies with IEEE 802.3ah
Complies with FCC47 CFR Part15, ClassB
Complies with FDA 21 CFR 1040.10and1040.11
