NGC（MIL-DTL-64266） Fiber Optic Connector-Aviation Connector

The NGC series fiber optic connectors minimize insertion loss, effectively reducing optical signal attenuation during the connection process and ensuring efficient transmission. NGC connectors offer excellent return loss performance and strong suppression of link optical power reflections, significantly reducing optical signal reflections and interference, thereby improving transmission quality. NGC connectors also offer excellent interchangeability and reusability. Connectors of the same type can be used in any combination and repeatedly plugged and unplugged with minimal additional loss, ensuring the long-term stability and reliability of fiber optic networks. The NGC connectors' robust mechanical structure withstands repeated plugging and unplugging and varying environmental conditions, resulting in a long service life and reduced maintenance and replacement frequency. NGC connectors exhibit excellent anti-interference performance, effectively preventing electromagnetic interference and lightning interference, and operating stably in complex electromagnetic environments.

The NGC series fiber optic connectors are primarily used in the military. In the air, they are used in naval aircraft communication, navigation, radar, and other systems, ensuring stable optical signal transmission during flight. They are also used in shipboard communication systems and sonar detection equipment, ensuring high-speed, reliable data transmission in complex marine environments. In space military applications, NGC connectors can connect the measurement, control, communication, and data transmission systems of satellites, spacecraft, and other spacecraft, meeting the stringent requirements of the space environment. Furthermore, NGC connectors also have a certain scope of application in certain high-end civilian applications that require extremely high connector performance, such as connecting core network equipment in high-speed data centers and long-distance trunk optical communication systems.

Product Introduction

Conforming to the MIL-PRF-64266B series standard
Imperial double-headed threaded quick connection with locking mechanism
Three-key circumferential recognition and positioning for blind insertion and error-proof insertion
The outer shell can be made of different materials and coatings to meet different environmental requirements
Detachable standard Φ1.25mm neutral fiber optic contact is adopted
Removable ASR components for easy cleaning and maintenance
The product applies mature and new technologies of connectors that meet the MIL-PRF-28876 and MIL-DTL-38999III series standards, and has better mechanical and environmental resistance performance

Optical Performance

• Insertion Loss: ≤0.5dB

• Return Loss:

• ≥30dB (MM, SM/PC)

• ≥40dB (SM/UPC)

• ≥60dB (SM/APC)

• Optical Discontinuity: 50μs, 0.5dB

Environmental Performance

• Temperature Range: -55°C to +165°C

• High-Temperature Life: 165°C for 1000 hours

• Salt Spray:

• Class A: 500 hours

• Class B: 500 hours

• Class F: 48 hours

Mechanical Performance

• Housing Material and Plating:

• A - Aluminum Alloy, Cadmium-Plated Military Green

• B - Stainless Steel, Passivated

• F - Aluminum Alloy, Nickel-Plated

• Mechanical Life: 500 mating cycles

• Shock Resistance: 300G

• Vibration Resistance:

• Sine Vibration: 60G

• Random Vibration: 1.0G²/Hz

Contact Arrangement (View of Mating Face at Socket End)
