GIGAC Technology's 30Kbps-50Mbps low-speed military-grade SFP+ optical module is specially designed for military and high-reliability industrial scenarios. It combines the stability of low-speed communication with adaptability to harsh environments, meeting the extreme requirements for optical modules in special fields. It adapts to the military wide temperature range of -55℃ to +105℃ and can withstand harsh conditions such as salt spray and high altitude. Integrating single-fiber bidirectional transmission technology, it saves 50% of optical fiber resources. Equipped with a high-sensitivity APD receiver and anti-radiation design, it achieves stable long-distance communication of 60km with power consumption ≤1.2W. With an all-metal anti-vibration structure, localized production technology, and national military standard certification, it is suitable for tactical communication systems, unmanned equipment control, aerospace buses, and border monitoring networks, meeting the needs of independent and controllable national defense equipment and low-speed, high-reliability data transmission in complex industrial scenarios.
Product Features:
SFP+ package, dual-fiber LC optical interface
Support hot swapping
Support transmission rate from 30Kbps to 50Mbps
VCSEL/FP/DFB laser transmitters and PIN detectors
Multimode 50/125um fiber transmission up to 2Km
Single-mode 9/125μm fiber transmission up to 60km
Single +3.3V power supply
LVTTL level signal input/output
Extremely low electromagnetic interference and excellent ESD protection
Application:
Low-rate 30Kbps-50Mbps optical fiber transmission system
RS232/RS485/RS422 optical fiber transmission
Other control optical links
Product Information Sheet:
model number | rate | wavelength | Transmission distance | Fiber optic types | Interface | Operating temperature (Note 1) |
DTACP44-YYLFJ1 | 30Kbps-50Mbps | 850nm | 2km | Multimodal | LC | -40°C~+85°C |
DTACP45-YYLFJ1 | 30Kbps-50Mbps | 1310nm | 2km | Multimodal | LC | -40°C~+85°C |
DTACP45-YYLLJ1 | 30Kbps-50Mbps | 1310nm | 10km | Single-mode | LC | -40°C~+85°C |
DTACP45-YYLGJ1 | 30Kbps-50Mbps | 1310nm | 20km | Single-mode | LC | -40°C~+85°C |
DTACP45-YYLEJ1 | 30Kbps-50Mbps | 1310nm | 40km | Single-mode | LC | -40°C~+85°C |
DTACP46-YYLEJ1 | 30Kbps-50Mbps | 1550nm | 40km | Single-mode | LC | -40°C~+85°C |
DTACP46-YYLHJ1 | 30Kbps-50Mbps | 1550nm | 60km | Single-mode | LC | -40°C~+85°C |
