The XG Combo SFP+PON OLT optical module and XGS Combo SFP+PON OLT optical module are optical communication modules used for optical line terminal (OLT) devices, supporting data transmission rates of 10Gbps and over 10Gbps respectively, and can support both EPON and GPON protocols through SFP+interfaces.
1.Features:
Support both ITU-T G.9807.1&G.987.2 XGSPON&XGPON OLT N1 and ITU-T G.984.2 GPON OLT B+ application.
Single fiberQuad-directional data links, and the four wavelengthscan work simultaneously XGSPON&XGPON1577nm 9.953G continuous-mode transmitter with EML laser,1270nm 9.953G&2.488G burst-mode receiver with APD-TIA(withRESET),with GPON1490nm 2.488G continuous-mode transmitter with DFB laser, 1310nm 1.244G burst-mode receiver with APD-TIA(with RESET)
2-wire interface for integrated digital diagnostic monitoring
Digital receiving signal strength indication (RSSI)
SFP+ MSA package with SC/UPC receptacle optical interface
+3.3V power supply
Operating case temperature: 0~70°C
RoHS2.0 compliance
2.Applications
FTTx networks, 5G wireless networks and other communication environments.
3.General
XGSPON&XGPON/GPON Combo OLT, compatible with GPON OLT B+ and XGSPON&XGPON OLT N1, Featuring TX 1490nm 2.488Gbps / Burst RX 1310nm 1.244Gbps, and TX 1577nm 9.95Gbps / Burst RX 1270nm 9.95Gbps, SFP+ form-factor, BIDI SC/UPC Receptacle, 0~70°C Commercial Temperature Range
4.Order Information
| Parameter | Part Number | Index level | Interface | Temp(1) |
| XG Combo PON OLT SFP+ | GCLP-0044-10 | B+ | SC | 0~70℃ |
| XGS Combo PON OLT SFP+ | GCLP-0045-10 | B+ | SC | 0~70℃ |
(1)The Temp is Operating Case Temperature Range.
